Technical Specs Name:

XPL-LD808T500

Wavelength:

808±5nm nominal center

Packaging type:

TO18

Type:

Direct Diode Laser

Transverse mode:

Multi mode

Operating mode

CW

Output power:

500mw

Arctic series class:

IIIB

Spectral width Δλ:

≤2.5

Beam shape:

100x1um

Beam divergence :

36×8 deg

Polarization:

TE

Slope efficiency Es:

>1.0

Threshold current Ith:

<0.1A

Operating current Io:

<0.55A

Operating voltage Vf:

≤2.0 V

Series resistance Rd:

≤1.0Ω

Packaging form:

C-Mount

Reverse voltage Vr:

2.0V

Operating temperature To:

25℃

Storage temperature Tstg:

-10-60℃

Continuousexpected lifetime:

>5,000 hours

Warranty:

One Year (LD died is not included)

Technical Specs Name:

XPL-LD808T200

XPL-LD808T300

XPL-LD808T500

Wavelength:

808±5nm nominal center

Packaging type:

TO18

Type:

Direct Diode Laser

Transverse mode:

Multi mode

Operating mode

CW

Output power:

200mw

300mw

500mw

Arctic series class:

IIIB

IIIB

IV

Spectral width Δλ:

≤2.5

Beam shape:

50x1um

50x1um

100x1um

Beam divergence :

36×8 deg

Polarization:

TE

Slope efficiency Es:

>1.0

Threshold current Ith:

<0.1A

Operating current Io:

<0.3A

<0.4A

<0.55A

Operating voltage Vf:

≤2.0 V

Series resistance Rd:

≤1.0Ω

≤1.0Ω

≤0.75Ω

Packaging form:

C-Mount

Reverse voltage Vr:

2.0V

Operating temperature To:

25℃

Storage temperature Tstg:

-10-60℃

Continuousexpected lifetime:

>5,000 hours

Warranty:

One Year (LD died is not included)
