Description
- Measuring Range: 10K ohm
- Brand Name: FUJIANG
- DIY Supplies: ELECTRICAL
- Model Number: WTH118
- Dimensions: 25 x 20mm
- Accuracy Class: 0.5
- Product Name : Carbon Potentiometer;Model : WTH118;Technology : Carbon Composition;Rated Power : 2W
- Resistance Value : 10K ohm;Tolerance : 5%;Turn Number : Single Turn;Terminals Number : 4
- Features : Round Shaft;Potentiometer Body Size : 28 x 15mm / 1.1″ x 0.6″(D * H);Potentiometer Total Height : 35mm / 1.4″;Rotary Knob Cap Size : 25 x 20mm/1″ x 0.8″(Max.D*H)
- Screw Thread Dia. : 10mm / 0.4″;Shaft Diameter : 6mm / 0.24″;Shaft Length : 9mm / 0.35″
- Color : Red, Black, Silver Tone;Net Weight : 30g;Package Content : 1 x Carbon Potentiometer
