1. X-Axis Motor (Contain X Axis Limit, Y Axis Limit)
2. X-Axis Motor(Trolley Motor)
3. Y-Axis Motor(Beam Motor)
4. ‘LO 5V GND 24V’ Port
LO: Laser Control Signal Output. High Level-No light Dipping,Low Level(<=0.3V)-Laser ON
5V: 5V Switch Power Supply
GND: Ground
24V: 24V Switch Power Supply
5. X Axis Limit, Y Axis Limit
6. The Main Board Code
7. If you use Power Supply, Connect LO to TL.
8. External Synchronous Control Signal Output
