Description
- Brand Name: laserlands
- Certification: None
- Origin: CN(Origin)
Product parameter
The following parameters are the laser parameters corresponding to the switching lens, which are for reference only.
Wavelength 400-700nm or 700-1100nm
Spot mode Dot
Output power 1-3000mw
Size 12*30.5mm
Optical fiber interface SMA905
Material Aviation aluminum and anodizing
Effective focal length10mm
Spot size Adjustable
Aperture of light 5mm
Optical system Optically coated non spherical lens
Transmittance>93%
Fiber spot Spot size is related to fiber core diameter
Divergence angle 0.5mrad
Fiber core diameter 4-600um (General)
