Description
- Brand Name: Go-Fibereasy
- Origin: Mainland China
- Item Length: 30m
- Compatible: Ubiquiti,QSFPTEK,Mikrotik,Transition Networks,Zyxel,Ericsson,Enterasys,Brocade,Mellanox,Alcatel-lucent,Customized Brands,Cisco,Arista,FOUNDRY,TP-link,Allied,Extreme,Dell Force10,Juniper,D-Link,Linksys,Netgear,HP,IBM,Intel,Trendnet,Open Switch,Dell,F5 Networks,Hirschmann,Moxa,planet,Supermicro,AVAGO,Avaya,Ciena,Finisar,H3C,SMC,Huawei,Aruba
- Fiber Type: Multimode
- Connector Type: Hybrid
- Model Number: GSFP-10G-TX
- Certification: CE,FCC,RoHS
- Size: none
- Form Type: SFP 10G Transceiver Module
- Max Data Rate: 10Gb/s TX
- Max Cable Distance: 30Meters
- Fiber Connector: RJ-45 Connector
- Cable Type: Cat 5e/6/6a
- Power Supply: 3.3V
- Low Power Consumption: 2.5W MAX @ 30m
- Protocols: IEEE 802.3az Compliant,IEEE 802.3an, IEEE 802.3az, SFP MSA, SFF-8431
- Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Welcome to Go-Fibereasy Official Store
Because some brands of switches only recognize their own code, please leave us a message about your switch brand, so that we can write the corresponding code to the SFP Modules
SFP+ to RJ45 Copper Fiber Optical Module 10GBase-Tx Ethernet Fiber Switch Module Compatible with Cisco/Ubiquiti/Netgear/Mikrotik SFP+ Module
SFP 10Gb RJ45 Copper SFP+ Module 10GBase-T Fiber Optic Transceiver SFP-10G-T-S Cisco/Ubiquiti/Netgear/Mikrotik Ethernet Switch
|
Features: |
|||
|
Supports Links up to 30m using Cat 6a/7 Cable |
|||
|
SFF-8431 and SFF-8432 MSA Compliant |
|||
|
IEEE 802.3az Compliant |
|||
|
Low Power Consumption (2.5W MAX @ 30m) |
|||
|
Fast Retrain EMI Cancellation Algorithm |
|||
|
I2C 2-Wire Interface for Serial ID and PHY Register Access |
|||
|
Auto-negotiates with other 10GBase-T PHYs |
|||
|
Multiple Loopback Modes for Testing and Troubleshooting |
|||
|
Operating Case Temperature Standard:0°C~+70°C |
|||
|
Applications: |
|||
|
CiscoNexus 2232TM-E 10GbE fabric extender |
|||
|
CiscoNexus 5596T switch, part of the CiscoNexus 5000 Series family of switches |
|||
|
CiscoNexus 7000 1/10GBASE-T line card, part of the CiscoNexus 7000 Series platform |
|||
|
Intel Ethernet Controller X540 and Intel®Ethernet Converged Network Adapter X540 |
|||
|
Panduit TX6ATM 10GigTM Copper Cabling Syste |
