Description
- Brand Name: laserlands
- Certification: None
- Origin: CN(Origin)
- Style: DMX Stage Light
- Model Number: QL80S4HD-Y
- Occasion: Home Entertainment
QL80S4HD-Y 9.0mm 500mW 808nm/810nm IR Infrared Laser Diode LD TO5
QL80S4HD-Y is a MOCVD grown 808nm band laser diode with quantum well structure.
It’s an attractive light source, with a typical light output power of 500mW for optoelectronic devices such as solid state laser pumping and medical use.
APPLICATION
-Solid state laser excitation
-Medical use
-Material processes
-Measurement
FEATURES
Optical Output Power: 500mW CW
Package Type : TO-5 (φ9mm)
Polarization : TM (Electric Field Perpendicular to the Junction Plane)
Note:
1. only for professionals.
This Infrared laser diode is an industrial electronic component and used for as Industrial test, Lab, DIY. NO HANDHELD LASE USE
The laser diode is precise and sensitive optical instrument. Before carrying on some laser DIY activities, please read about the technical information first and protect your eyes before laser ray. Be sure the operator has experience in optics DIY or test. and Don’t operate when the power is connected.
Do not touch the ld by your hands directly. Please use anti-static wrist strap.
