Description
Products Features:
1.LEDdigital screendisplay,voltage, current, power, power factor/frequency
2.All measurements are Trms
3.Automatic range
4.Accuracy: 0.2
5. Not affected by external noise
6.Support data locking
7.Can be setcurrent and powerlower and upper alarm function, PASS the light is Green, NG the light is Red, Easy to distinguish
Areas of Application:
Power consumption test for household appliance
Power consumption test for the air-condition
Power consumption for light products
Power consumption test for LED Lamps
Test for electric machine and Motor
Test for chargers and switching power supply
Specifications:
|
Connection |
Single Phase, three-phase three-wire system two-unit method, three-phase three-wire three-unit method and three-phase four-wire system |
|
Display |
LED Digital screen |
| Measuring | Voltage-V, current-A, active power-W, reactive power Var, apparent power VA, power factor PF, Frequency Hz, Phase angle ph |
| Voltage Range | 5V-600V AC(Switch the range automatically
Peak Voltage:700V AC Min test voltage:5V AC |
| Current Range | 10mA-40A AC(Switch the range automatically)
Peak current:50A AC Min. test current :10mA AC |
| Power Range | 0.1W-12KW
(Note: the ranges of active power, reactive power, apparent power are consistent) |
| Power factor Range | 0.001-1.000
Compute mode: watt(W)/[Voltage(V)*current(A)]=Power factor(PF) |
| The frequency range | 45-65Hz |
| Electric Energy | ±0-9999.99 KWh |
| Communication Interface | Standard RS232, Harmonic Testing software, optional Relay output |
| Basic Accuracy |
±(0.4% reading +0.1%range+1 digit) |
| Measuring Speed | Five times per second |
| Input Impedance |
About 2MΩ(All voltage) |
| Power Supply | AC (100-250)V 45/400Hz, DC (100-300)V |
| Volume and weight | 430mm(L)*360mm(W)*155mm(H), 9.0KG |
| Attachment | Power wire, the warranty card, specification; |
