Description
- Item Type: Stage Lighting Effect
- Style: DMX Stage Light
- Occasion: Professional Stage & DJ
- Model Number: LM12WRGB
- Power: 100W
- Voltage: 90-240V
- Brand Name: DYUE
- Laser Name: 12W RGB Laser Module
- Color: RGB Color
- Guaranteed power: 12W
- Power Red: more than 3.4 W / 635 nm
- Power Green: more than 2.5 W / 520 nm
- Power Blue: more than 6 W / 447 nm
- Beam Specifications: ca. 6 mm / 2 mrad
- Laser Sources: Diode, DPSS Laser
- Laser Class: 4
- Power supply: 85V – 250V AC
- CW Laser: ILDA Laser Show
OEM CW Laser Module High Power 12W RGB Laser ModulesFor Laser Show
Color diode laser at 635,520,447nm is made features of long lifetime,low cost and easy operating, which is widely used in ILDA laser show
Wavelength: 635/520/447nm ( error range 5mm)
Operating mode: CW
Output power:12W
Ratio power: Red laser more than 3.4W, Green laser more than 2.5W, Blue laser more than 6W
Power stability: less than 1%, less than 3%, less than 5% (rms, over 4 hours)
Beam diameter: 6X6, 3.5X5, 3.2X3.2 (mm, at the aperture)
Beam divergence: 1.9X2.3, less than 1.4X0.8, less than 1.4X0.2 (full angle, mrad)
Polarization direction: Horizontal + Vertical
Warm-up time: less than 5 minutes
Beam height from base plate: 30mm
Operating temperature: 25 degrees celsius (error range 3)
Power supply: 100-240V AC (12V 20A)
Modulaton option: TTL / Analog
Expected liftetime: 10000 hours
Warranty: 1 year
