Power Measurement Range dBm

-70~ + 10

-50~ + 26

Nm wavelength measurement range

800~ 1700

Nm wavelength calibration

850, 1300,1310,1490,1550,1625

Probe Type

InGaAs

Measurement Accuracy

<± 3% (- 10dBm, 22 )

Display resolution dB

Linear Display: 0.1% , logarithmic display : 0.01dBm

Operating temperature

-10~ + 50

Storage temperature

-20~ + 70

Relative Humidity

90%(+ 30 ), non-condensing

Optical Interface

FC, SC (ST LC optional )

Power supply

7Number three AAA batteries

Battery continuous operation time h

120Hour

Auto- off time min

10

Weight g

160

Dimensions (mm)

130× 63 × 29
