KTC-400mm Dynamic multicontour seat linear motion position sensor Analog Sensor potentiometer

$159.00

SKU: 1005002917589356 Category:

Description

  • Brand Name: LanYuXuan
  • Certification: CE
  • Origin: CN(Origin)
  • DIY Supplies: ELECTRICAL
  • Place of Origin: Guangdong, China
  • Model Number: KTC-400mm
  • Brand Name: MINUO
  • Usage: Position Sensor
  • Theory: Resistance Sensor
  • Output: Analog SENSOR
  • Materials: Anodized aluminium , Stainless Steel etc
  • Weight(150mm): 0.55KG(package of one piece)
  • Measure Range: 0-1500mm
  • Type: pull rod type
  • Operating Temperature: -50– 150℃, -40-120
  • Max. Operating Voltage: 24V
  • Independent Linearity: ±0.05%
  • Output range: Voltaage divider
  • Resolution: infinite
  • Interface: Analog
  • Technology: Resistive
  • Voltage – Supply: 10V 5V 12V 24V
  • Output Type: 0-10V 0-5V 0-12V 0-24V
  • Current – Supply: 24
  • Resolution (Bits): infinite
  • Operating Force: 10N
  • Size / Dimension: 32*33
  • Measuring Range: 0-1500mm
  • Resistance: 5k
  • Resistance Tolerance: 20%
#detail_decorate_root .magic-0{border-bottom-style:solid;border-bottom-color:#53647a;font-family:Roboto;font-size:24px;color:#53647a;font-style:normal;border-bottom-width:2px;padding-top:8px;padding-bottom:4px}#detail_decorate_root .magic-1{width:750px}#detail_decorate_root .magic-2{overflow:hidden;width:750px;height:1017.1875px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-3{margin-top:0;margin-left:0;width:750px;height:1017.1875px}#detail_decorate_root .magic-4{width:750px;border-collapse:collapse}#detail_decorate_root .magic-5{min-height:18px;padding:5px 10px;width:126px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-6{min-height:18px;padding:5px 10px;width:344px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-7{min-height:18px;padding:5px 10px;width:154px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-8{text-align:center}#detail_decorate_root .magic-9{width:320px}#detail_decorate_root .magic-10{overflow:hidden;width:320px;height:212px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-11{margin-top:-84px;margin-left:-1px;width:320px;height:320px}#detail_decorate_root .magic-12{overflow:hidden;width:320px;height:212px;margin-top:4px;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-13{margin-top:-68px;margin-left:-1px;width:320px;height:320px}#detail_decorate_root .magic-14{overflow:hidden;width:426px;height:426px;margin-top:0;margin-bottom:0;margin-left:4px;margin-right:0}#detail_decorate_root .magic-15{margin-top:0;margin-left:0;width:426px;height:426px}#detail_decorate_root .magic-16{vertical-align:top}#detail_decorate_root .magic-17{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-18{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root .magic-19{padding:0;margin:0;white-space:pre-wrap;font-size:14px}#detail_decorate_root .magic-20{font-size:18px}#detail_decorate_root .magic-21{overflow:hidden;width:373px;height:410px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-22{margin-top:-43px;margin-left:-1px;width:373px;height:497.3333333333333px}#detail_decorate_root .magic-23{overflow:hidden;width:373px;height:410px;margin-top:0;margin-bottom:0;margin-left:4px;margin-right:0}#detail_decorate_root .magic-24{margin-top:0;margin-left:0;width:373px;height:497.3333333333333px}#detail_decorate_root .magic-25{overflow:hidden;width:750px;height:937.5px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-26{margin-top:0;margin-left:0;width:750px;height:937.5px}#detail_decorate_root .magic-27{overflow:hidden;width:750px;height:870.9375px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-28{margin-top:0;margin-left:0;width:750px;height:870.9375px}#detail_decorate_root .magic-29{overflow:hidden;width:750px;height:763.125px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-30{margin-top:0;margin-left:0;width:750px;height:763.125px}#detail_decorate_root .magic-31{margin-bottom:10px;overflow:hidden}

Products Description
Details Images
Product packaging
Each product has its own packaging
Shenzhen MINOR electronic co., LTD., founded in 2004, main production and sales of conductive plastic displacement sensor(electronic ruler), Angle displacement sensor (including auto direction power sensor, gas sensor, throttle sensor, car seats,gearbox sensor, etc.), Pull rope (line) displacement sensor ,transmitter, magnetostrictive displacement sensor, intelligentdigital display table, grating feet, range from 5 mm to 30 m, product accuracy is 0.1%, 0.05%, 5um, 1um variety, completespecifications and models, range range service life and accuracy in the leading position in the industry.
