Description





Product Detail:

Features – MQW LD optical source –

Operating mode: CW and GLINT –

FC, SC, ST,LC General interface –

Long inspection distance –

Steady power output –

Sturdy and durable shell –

Pen pattern design, convenient for use and carry



Function

– Locate the fiber failure, such as fracture and bend

– Failure inspection in OTDR blind zone

– Fiber recognition from head face to end face

– Mechanical transition point optimization



Application

– Telecom, CATV project

– PDS construction and maintenance

– Optical component manufacture and research

– Other fiber project

Technical Parameter

– Wavelength: 650+/- 10nm

– Fiber mode: 2.5 mm Universal

– Output power: 1mW

– Inspection distance: 1-5KM

– Electrical source: Two 1.5V Batteries (NOT include)

– Working time of batteries: More than 15 hours

– Operating Temperature: -10- +60 degree C

– Storage Temperature: -20- +70 degree C

– Material of shell: Alum-alloy

Note:

since the international air does not allow contains flammable and explosive goods, so the unity does not contain the battery delivery, thank you for understanding!
