Description
Dilas 808nm Laser Diode Hair Removal Machine Repair Dilas Laser Handpiece RepairDilas Laser Handle Repair
Dilas 808nm Laser Diode Hair Removal Machine Repair
Dilas Laser Handpiece Repair
Dilas Laser Handle Repair
We can repair and manufacture lasers, and repaired brands include Alma, Syneron, Gunay, Focus light, Nlight and so on.
Micro-second Quick-Freezing Cooling Technology-Annual TEC used in handle breaks through traditional TEC application and prolongs the life of handles!
Product Description
Specification
| Model No. | MI-100-3-Dilas-housed |
| Application | Dilas Repair and Replacement, exp:Honkon laser |
| Operation Mode | CW |
| Power per Submount | 100W |
| Number of Submounts in One Stack | 3 Bars |
| Central Wavelength at 25℃ | 808± 5nm |
| Typical Operation Current | 85A |
| Maximum Operating Current | 100A |
| Typical Threshold Current | 15A |
| Maximum Operating Voltage | <6 V |
| Fast Axis Divergence(FWHM) | 39° |
| Slow Axis Divergence(FWHM) | 8° |
| Operation Condition | 10k-class cleaning room |
| Expected Lifetime | 10000hours |
| Typical Pitch Per Bar | 1.8mm |
| Cooling Requirement | |
| Flow Rate | 1.5L/min±10% |
| Water Temperature | 25± 3℃ |
| Water Quality | Deionized 2-10 µs/cm, mixed bed ion exchanger,particle filter<25µm |
| Cooling System | Do not use any material that would form galvanic elements once combined with copper |
Our Services
You Can Choose The Following Services:
| Repairing procedure | Advantages |
| Chioce A: Send the old broken handpiece to our factory. We will do the process of checking , repair, cleanning and etc. Then send the new handpiece back to you. | Save Money. Replace the broken diode stack only. Low-cost and more convenient. |
| Chioce B: if you have basic assembly capacity, you can only send the diode laser stack to our factory. We remove the old bar and mount the new bar to recover the laser power of the stack. | Long life time. We use diode laser bars from Germany. The newest Ausn mounting technology will be applied when repairing. After repair, the handpiece will be as a new one. Life time is much longer than before |
| Choice C: Measure your stack and comfirm the water pipe hole and screw hole position. Then buy a ready-made stack which matches your old handpiece. | All technical support available. We major in diode laser mounting, software, spare parts over 16 years. All the technologies about laser hair removal machine are open to you. |
