Description

Specification:                                                                  Multi-functional simulation extended board FB2530EB support a variety of RF main control module (for example FB2530RF, etc.), configure the serial and parallel LCD interface, DC 5V power connector, battery interface, RS232 interface, the DEBUG interface, five-phase button and indicator light, infraredremote control signal receiver / transmitter module.
Feature:

1.power supply section.DC 5V power supply and battery-powered
2.the LCD part.FB2530EB LCD module provides serial and parallel the two interfaces
3.serial section (RS232)
4.the RF interface part.Multi-functional simulation expansion the board FB2530EB master part for the external RF control module.
5.DEBUG interface section.Multi-functional simulation extended board FB2530EB DEBUG interface P11 connected to the CC DEBUGGER
6.buttons and indicator part.Multifunctional simulation expansion board FB2530EB a five-button (U1), four touch of a button (S1/S2/S5/S6), and six LEDs (D5/D6/D7/D8/D15/D16) display.
7.the infrared remote control signal input and output parts (The RemoTI platform only)

Package:

FB2530EB  x1
