Description

Big thick Beam 60mW 532nm pumped solid state picosecond Laser Diode Module w/TTL

Output Power 60mw
Wavelength 532nm
Working Voltage 12VAC DC
Working Current <600mA
Working Temperature -10 degrees C- 30 degrees C
TTL Yes
Laser Shape Dot
Divergence 15mm
Lens Glass
Dimensions 35*35*80mm
Beam Diameter: 12mm-15mm
Working Life >5000 Hours

Feature:
1. This laser module can not work for a long time if there is no cooling device to keep the laser working under 30 degrees C.
2. Please add a 12VDC power to this laser module. Please add the power to the “12V+” and “12V-“. If you don’t use TTL(Blonk+,Blonk- in the middle), please just leave them unconnected.
3. This is a laser module for Laser show. Please protect the lens and keep it clean and avoid dust.
4. Please wear 532nm laser protection goggles to protect your eyes when working on this module.
