Description
9*21mm 635nm 10mw Red Cross Laser Module 50 degree Fixed Focus
Specifications：
Size: φ9 × 21mm
Material: Aluminum
Surface Treatment / Color: Black
Life: continuous output and life> 10,000 hours
Output wavelength: 635nm / ± 5nm
Output power: <10mw
Range: 20M
Spot shape / Diameter: Cross, 50 degree
Width: 1m, < 3mm
Circuit control: APC circuit
Operating Voltage: DC 3V
Working Current: <80mA
Conductor: 150MM red and black electronic circuit
Working temperature: -10°C ~ +50 °C
Storage temperature: -20 °C ~ +60 °C
Application module:
1 can be used for sight with positioning.
2 can be used for laser testing tools.
3 can be used to locate concentricity.
4 can be used to locate medical equipment, beauty.
5 can be used to produce a signal device.
