OSRAM SPLPL90-3 SPLPL90-3 pulsed laser tube 75w 905nm

Model: SPLPL90-3 pulsed laser diode
Brand: OSRAM

Package: DIP2

Detail:
Optical type FP
Wavelength λ (nm) 905
Spectral width Δλ(nm) 7
Peak output power Pop(w) 75
Spot size w*h(um) 200*10
Number of light strips (n)
Divergence angle θ‖*θ⊥(°) 11*25
Duty cycle (%) 0.1
Pulse width (ns) 100
Operating temperature Top (°C) – 40 + 85
Storage temperature Tstg (°C) – 40 + 100
Package DIP-2
Packing: 50PCS/pack vacuum packing
Peculiarity:

Peak optical power up to 75 watts

Laser wavelength 905 nm

Suitable for short laser pulses from 1 to 100 ns

High heat resistance (operating/storage temperature range: -40°C ~ +100°C)

· SPL PL90_3 uses Nanostack chip technology to achieve a typical optical output of 70W ~ 75W

· Nanostack laser technology, which includes 3 epitaxial technology integrated emitters

Laser aperture 200 microns× 10 microns

・Luminescence wavelength (905 nm)

Lead-free design, RoHS compliant

・Cost-effective resin encapsulation

Apply:

Hand Held Laser Rangefinder (LRF) golfer, hunter, civil engineer

Smart car applications (adaptive cruise control (ACC), collision detection, collision avoidance, adaptive rear taillights)

Traffic monitoring (laser speed gun, traffic recording, vehicle classification, distance measurement, fog detection)

Professional laser distance sensor measurement, positioning, protection
