60W~200W fiber-coupled direct diode lasers

Description

60W~200W fiber-coupled direct diode lasers

Applications
 plastic welding
 Welding
 soldering

Optical specification
Wavelength: 915nm or 980nm
Fiber Core[N.A.]: 105μm [NA 0.22] 105μm [NA 0.22] 135μm [NA 0.22]
Fiber length: 5m
Fiber Termina:l SMA905
Aiming beam: Red
Operation Mode: CW or Modulated
Polarization State: Random
Output Power Instability(25℃):<2%(2hrs)
Output Power Tunability: 10%-100%
Modulation Frequency:  20kHz
Electrical Characteristics
Voltage: Single phase,220±20V,AC,PE,50 or 60Hz
Power consumption at nom. Power, approx: <500W
Interface: Touch screen, RS232, AD control
Refrigerating method: Air cooling Water cooling Water cooling
Others
Weight: 40 kg 46 kg 66kg
Dimensions: 5U (220 mm), 710mm depth
Temperature: 10 – 45 ℃ operational, 5 – 65 ℃ storage
Humidity: max. 75% @ 25℃, non condensing
Protection rating: IP54
Safety class: 4 (EN 60825-01)

Product parameters
