Description
Feature:
This laser locator/module has is widely used in clothes cutting, wood cutting, mechanical positioning.
If you want to prolong the duty cycle, please add additional heatsink, otherwise the laser diode ‘s life will be shorten greatly, and the output of the laser will reduce very soon.
Parameter:
Wavelength: 532nm
Output Power: 45-55mW
Working Voltage: DC = 3-5V
Circuit control: ACC line
Working Current: I <250mA
Light shape: 110 Degrees Line(Can be customized 5mW, 10mW, 20mW, 50mW, 100mW, 120mW)
Warm-up time: None
Operating temperature: +20 ℃ ~ +30 ℃
Storage temperature: +10 ℃ ~ +40 ℃
Duty Cycle: 20 minutes on, 3 minutes off
Structural features: laser diode + crystal + glass len
Cross Section size: 21x21mm
Dimensions: ￠25 mm X 75mm
Detail:
This laser locator / module has is widely used in cutting clothes, wood cutting, mechanical positioning.
If you want to extend the duty cycle, add additional heat sink, otherwise the life will be significantly shortened from the laser diode, and the laser output will reduce very soon.
Package:
1pc 532nm 50mW Line Green Laser Diode Module
