Description
- Certification: CCC
- Shape: Square
- Model Number: RZX-S2525CB-1W
- Luminous Flux(lm): 20-30LM
- Color Temperature: Blue450-470NM
- Forward Current: 20-350MA
- Material: Ceramic
- Forward Voltage: 2.8-3.4V
- Package Type: Suface Mount 2525Package
-
Specifications: 1W
1. Brand new and high quality.
2. LED emitter: 1W. Forward Current: 20-350mA
3. Emitted color: Blue
4. Color temperature: Blue 450-470NM
5. DC forward voltage (VF): 2.8-3.4V ,
6. Beam angle: 120 degrees.
7. LifeSpan time: > 50,000 hours.
8. Intensity luminous: Blue 20-30LM
9. RoHs compliant, lead free.
-
Package included:50Pieces/Lot
– High power LED light source
– Instant light (less than 100 ns)
– Low voltage DC operated
– Low thermal resistance
– RoHS CompliantNote :
They may burn out if they receive enough power with no cooling , And if you use it for a long time,
please give them colling!!!
High Power LED Series
2525(1W )
Dimension
2.45×2.45×1.85mm
Power Consumption
1W 2.8-3.4V
Color Temperature
Blue450-470nm
Efficiency
20 lm/W(WW)-30 lm/W(CW)
Lumens Output
20 lm(WW)-30 lm(CW)
CRI
70
Application
MR16 MR11 GU10Spotlight/Streetlight / PAR38
The 2525 series is RZXLED’s newest surface mount high-power device featuring high brightness combined with a compact size that is suitable for all kinds of lighting applications such as general illumination, flash,spot, signal,industral and commercial lighting. The 3535 series is one of the most promising devices in RZXLED’s high power product offering and is ready to face the challenges of today’s Solid-State Lighting requirements.
