Description
Product Features
1. The quality of the spot is good, the performance is stable and the modulation efficiency is high.
2. Light, convenient, easy to integrate
3. Wavelength: Blue laser-445nm, Continuous output power greater than 5000 mW
Product parameter
1.TTL output power : 5-5.5W
2.Output stability : ±5%
3.Beam Mode : Square spot
4.Focus spot size : 0.2*0.8mm
5.TTL trigger mode : Active high(>DC 2.0V)
6.Analog control input voltage : DC 0–5.0V
7.Preheating time : <1Minute
8.Ambient temp : 15℃–50℃
9.Working life : >10000 Hours
10.Lens material : Professional focused optical glass
11.Spot divergence angle : <2mrad
12.LD input voltage : 4.7V
13.LD input current : 4.6A
14.Input voltage: DC 12V
15.Input power: 55.2W(12V/4.6A)
16.Output current: LD>2A
17.Constant current accuracy: Output current stability less than 1%, Output ripple is less than 100mW
18.Drive and power connection: 22#AWG
19.TTL input maximum voltage: DC 5V
20.TTL input response voltage: DC2.0V
Noted:
★ 1. The laser is potentially harmful to the human body and eyes. It is strictly forbidden to irradiate other people with laser, especially the eyes.
★ 2. The power supply itself has no key switch, and the power board and input wire are exposed. When the laser is connected to or removed from the circuit, it must be operated in the power-off state to prevent electric shock.
★ 3 It is necessary to ensure that the temperature of the laser head housing is close to the suitable working temperature before turning on the laser, so as to avoid excessive temperature difference, affecting the performance of the laser or damaging the device.
★ 4. This product should be used in a dry, clean and static-free environment, the working environment temperature is 15-50 ℃, avoid high temperature, high humidity, severe vibration and impact.
★5. Do not adjust the potentiometer on the power board at will, so as to avoid excessive current and burn out the circuit board or laser.
★6. Please take measures to dissipate heat outside the case and try to keep the heat dissipation air path of the case consistent with the heat dissipation air path of the module, so as to avoid excessive temperature which may affect or damage the laser.
★7. The power supply of this product is DC-12V. Do not connect to other power sources to avoid damage to the laser.
| Wavelength(nm) | 445nm |
| Output power(mw) | 5500mw |
| Power stability(rms,8hours) |
±5% |
| Warm-up time(minutes) | <1 |
| Beam divergence, full angel(mrad) | <1.2 |
| Beam diameter at the aperture(mm) | <1.5 |
|
Operating temperature(oC)
Power supply |
15~40 |
| Beam mode | Near TEM00 |
| Power supply |
DC6~12V, AC5V~12V |
| Warm-up time(minutes) |
1 |
| Expected lifetime(hours) |
5000 |
| Warranty period | 1 Year |
