Description

3 parallel line effect: red, green, blue, laser module, parallel line, positioning light, laser light

[Specifications]
Product Name: Laser Module
Laser Color: Red / Green / Blue
Wavelength: Red 650nm / Green 520nm / Blue 450nm
Laser Shape: Rectangle
Power: 100mW
Installation Height: 0~3 meters
Working Voltage: DC 2.8V~5.2V
Working Current: <500mA
Dimensions: 16*70mm
Optical Lens: Grating sheet (imported from Germany)
Lens Angle: 31°

At 50 cm: the length of the line is 27.6 cm, the width of the 3 parallel lines is 5.6 cm, and the distance between the lines is 2.8 cm
At 100 cm: the length of the line is 55.2 cm, the width of the three parallel lines is 11.2 cm, and the distance between the lines is 5.6 cm
The wire is thin and uniform, the collimation and stability are very high, and the installation height can be used from 0 meters to 5 meters

1 High brightness, clear and bright, and soft and not dazzling

2 The light size is adjustable to meet your different usage requirements

3. The shell is made of aviation aluminum-plated insulating paint, which can not only fully dissipate heat, but also shock-proof, anti-drop and anti-static

4. The imported laser diode directly emits light and has a particularly high stability and can be turned on 24 hours a day

5 Intelligent driver board with imported IC can supply 2.8-5.2V ultra-wide range of power supply (other voltages can be customized)

6 High temperature resistant corrosion resistant DC plug cable is suitable for all-weather and all-environment use

7. Wavelength, power, wire length, working distance, spot effect, etc. can be customized according to customer requirements

[Package Include]
1 x Laser module
1 x Power supply
1 x Laser module holder
