Description

266nm Laser Passive Q-switched Pulsed Semiconductor Laser with 10mW Output Power

There are 4 types of 266nm laser

Passively Q-switched UV Laser at 266nm
Actively Q-switched UV Laser at 266 nm
Picosecond Pulsed UV Laser at 266 nm
Fiber Laser at 266 nm CW Laser

TEC cooled
Long life operation
Analog/TTL modulation
Collimated straight beam
High efficiency
High reliability

APPLICATIONS
Biology
Biochemistry
Material Inspection

Wavelength 266+/-5nm
Spatial Mode Multi-mode
Output Power 10mW
Operation Mode CW or Modulation
Beam Size 2mm

Beam Divergence(full angle) 1.50 or 2mrad
Fibercoupling acceptable >=25um NA0.22
Power Stability <3% per 4 hrs
Temperature Stabilizing TEC
Warm Up Time <1 minute
MTTF 10,000 hrs
