Description

808nm QL80R4SD Infrared Laser Diode Special Offer 200mW

QL80R4SD 808nm 200mW Laser diodes Low price

description:
Output power: CW 200mW
Working current: <200mA
Working voltage: 1.9-2.5V
Package form: T018 (5.6mm)
Working life: more than 10,000 hours
Optical Output Power:200mW
Laser Diode Reverse Voltage:2V
Photo Diode Reverse Voltage:2V
Operating Temperature:-10~+40℃
Storage Temperature:-40~+85℃

The applicatioin for the laser diode is for an illuminator for the ophthalmic imaging device . The wavelength and optical power are important. The 808nm diode is used for an ICG fluorescence application. At this point, we are comparing the 780nm and 808nm as well as the 0.2 watt vs the 1.o watt emission.
