Specification
Wavelength	10600 nm/10.6μm
Times	2.5 times
Material	ZnSe
Input CA (mm)	12
Output CA (mm)	20
Diameter(mm)	25
Length(mm)	58
Raw Material	CVD ZnSe
Country of Origin	USA
Application	Widely used in the following brands CO2 laser engraving & cutting machines
Lifespan	3000-6000 Hours
Applicable Material	Leather, cloth,glass,acrylic,wood,color board ,Metal ect.
Applicable Machines	Redsail, Kaitian, Yueming, Goldenlaser, Senfeng, Shenhui, York Laser, Hanma Laser, Ruijie, and Bodor, ETL, etc.





Professional Design

Beam expander is composed with two lens of different curvature to obtain best effect.

Master Laser ^TM beam expander has been proved to have perfect curvature with small divergence angle and less energy loss.

Replaceable Incident Mirror/ Eyepiece

The role of beam expander is to expand beam spot.

The laser enter the beam expander where we called

eyepiece, it is easily broken due to high power.

The incident lens of beam expander produced by

Master Laser ^TM is replaceable (we don’t suggest

for other brands).



Polishing

The light transmission of the parts increased by cylindrical surface polishing, reduction or elimination on stray light of the optical system

Coating Film



Double-side coated anti-reflection coating

The transmittance of working waveband in co2 laser industry reaches 99.9%

Thin-film coating anti wiping

Higher luminous flux

Decrease or eliminate the reflective lights from optical lens

USA CVD ZnSe



Adopted ZnSe material imported from USA which can go with high power density, and increased the light transmittance of the parts

CVD ZnSe imported from America, boasting low material absorption rate, excellent high-power density endurance,

Great scratch resistance.

Shape & Structure



Stable focus spot, better effect in cutting and engraving, bearable for high power density, and strong thin – film coating against peeling off and durable for wiping.
