Description
- Brand Name: laserlands
- Certification: None
- Origin: CN(Origin)
- Style: DMX Stage Light
- Model Number: N/A
- Occasion: Home Entertainment
INDUSTRIAL 1845 Focusable 980nm 30mw 60mW 120mw 180mw Infrared IR Laser DOT Diode Module TTL 100khz 1845
980nm IR Laser Focusable Dot Diode Module w/ TTL
This 980nm laser dot module with a driver built-in is an industrial electronic component and used for industrial test, Lab. Not a handheld laser
The IR laser module is and precise and sensitive optical instrument. Before carrying on some laser DIY activities, please read about the technical information first and protect your eyes before laser ray. Be sure the operator has experience in optics DIY or test. It is invisible by bare human eyes and can only be seen by CCD or night version devices.
Specification
Output Power 30mW/60mW/120mW/180mW
Wavelength 980nm
Working Voltage 5.0VDC
Working Temperature -10 centi-degree~40centi-degree
Dimensions ø18mm*45mm
Working current <300mA
TTL : 0-5V
Frequency: 0-100KHz
Red wire for + pole, black wire for – pole, yellow wire for TTL + pole.
Package one 980nm 30mw Laser Dot Diode Module
NOTE:
1. 100KHZ high frequency–quite different with the 35khz low frequency.
2. red wire for voltage + pole, black wire for voltage – pole. black wire also for TTL – pole
3. you have to add at least 1000khz signal on the yellow wire for TTL effect. if not, you cannot get the TTL effect
ONLY FOR PROFESSIONALS
