Sale!

15S 16S 17S 6A balance Active Equalizer Balancer Lifepo4 LFP Li-Ion ion LTO Lithium Battery Energy Transfer BMS 48V 60V 1A 3A 5A

$79.00

SKU: 4000433847902 Category:

Description

  • Brand Name: Olive Leaf
  • Certification: None
  • Accessory Type: Battery Accessories
  • Origin: CN(Origin)
  • Model Number: Active Balancer

The price is only include balancer , don’t include battery or case

LTO Titanium version

Balanced starting voltage: 2.0V-2.8V
End-of-balance voltage: 1.9V (enter the under-voltage sleep state)
Balance accuracy: 5mv
Maximum balance current: 0.1V1A; 0.5V3.5A; 1.0V5.5A (18awg 30CM cable test)
Sleep current: ≤1mA
Quiescent current: fully charged (2.8v * cell) 12mA / 15mA
No external power supply is needed, relying on the internal energy transfer of the battery to balance the entire group.
Working environment temperature: 0-60 degrees

3.2V Lifepo4/LFP 3.7V Li-ion version

Balanced starting voltage: 3.0V-4.2V
End-of-balance voltage: 2.9V (enter the under-voltage sleep state)
Balance accuracy: 5mv
Maximum balance current: 0.1V1A; 0.5V3.5A; 1.0V5.5A (18awg 30CM cable test)
Sleep current: ≤1mA
Quiescent current: fully charged (4.2v * cell) 71.4V 10mA
No external power supply is needed, relying on the internal energy transfer of the battery to balance the entire group.
Working environment temperature: 0-60 degrees
