Description

1550 nm band wide bandwidth IQ Modulator

The MXIQ-LN-30 is a wide bandwidth, low insertion loss Dual Parallel Mach-Zehnder Modulator. Our proprietary “Magic Junction” confers it an unmatched low insertion loss, and its X-cut design guarantees high stability and zero chirp in a wide range of operational conditions.

MXIQ-LN-30 modulator is a key device dedicated to complex modulation scheme such as QPSK, QAM and OFDM up to 56 Gbaud.

Datasheet for 1550 nm IQ Modulator

FEATURES
Wide bandwidth
X-cut for high stability
Low insertion loss

APPLICATIONS
QPSK, QAM, OFDM
RELATED EQUIPMENTS
Analog driver DR-AN-HO
MBC-IQ Automatic Bias Controller
ModBox-IQ
