Description

1310nm SLED broadband Light Source Fiber Laser benchtop Source,High Precision ATC and APC Control Circuit, High stability and reliability, Broadband spectrum.

Applications:

Optical Communication
Optical Passive device testing
Spectrum analyses
FBG Optical Sensor System
Optical Communication
Optical Passive device testing
Spectrum analyses

Features:
High Precision ATC and APC Control Circuit
High stability and reliability
Broadband spectrum

Parameter:
Central wavelength (nm):1310+-10
Spectrum width (nm)(3dB):>50
Output power(mw):1,5,10,20,30,35
Ripple:<0.2dB
Output power short term stability:<+-0.01dB/15 min
Output power long term stability:<+-0.03dB/8 hour
Operating mode:CW
Fiber pigtail:Single mode SMF-28
Output connector:FC/PC, FC/UPC or FC/APC
Operating temperature:0~ 40
Storage temperature:-20~ 70
Power supply:110/220V AC+-10%,50Hz,20W
Dimensions(L*W*H):322*220*88
