| Optical |
| Wavelength (nm) |
808 |
| Wavelength Tolerance (nm) |
3 |
| Operating Power (W) |
10 |
| Emitter Size (µm) |
200 |
| Slope Efficiency (W/A) |
1.05 |
| Spectral Width FWHM (nm) |
2.5 |
| Spectral Width FW90%E (nm) |
5 |
| Fast Axis Divergence (90%, degree) |
70 |
| Slow Axis Divergence (90%, degree) |
10 |
| Wavelength Temp. Coefficient (nm/C) |
~0.28 |
| Electrical |
| Threshold Current (A) |
1.5 |
| Power Conversion Efficiency (%) |
48 |
| Operating Voltage (V) |
2 |
| Operating Current (A) |
11 |
| Thermal |
| Operating Temperature (C) |
15~35 |
| Storage Temperature (C) |
-40~60 |
| Recommended Heatsink Capacity (W) |
16 |
| 1. Data at the temperature of 25 degree C, unless otherwise stated.
2. For fast axis collimation: Divergence < 4 o
3. Under normal operating condition, the lifetime of the diode is 10,000 hours
|
