Description
1pc SHARP 505nm 35mW Green Laser Diode GH05030C2LM
Features: .
Wavelength: 505nm
Output power: CW 35mW
Working current: Max 100mA
Working voltage: max 7.5V
Packing: TO18 (5.6mm)
Operating temperature: -10 / +60 ℃
Storage temperature: – 40 ° C / + 85 ° C
Welding time: less than 10 seconds
Welding temperature: less than 260 ℃
Service life: less than 10,000 hours
Precautions:
This component is sensitive to static
electricity, not the anti-static measures. Do not touch the laser tube
body directly with your hand. In addition to this product, there must be
a qualified driving circuit to work properly different, The driving
current must be regulated in the safe range, otherwise it will affect
the service life.
