Eleksmaker USB Port CNC 3axis 2 Phase 4-Wire Stepper Motor Controller Board Mainboard for DIY Laser Engraving Machine CNC Router

Description

3-Axis CNC Stepper Motor Driver Board Laser Motherboard Kit Laser Engraving Control Board for CNC Engraving Machine

Built in three A4988 drivers, one 3 axis control board can be directly connected to 35.42, one small optical drive sliding table and another four wire and four-wire stepper motor with 1.5A tailgate current.
The laser controller board adopts three high power output modes for Microsoft Office specialized switch, life time and relay, support laser and pin motor control.
Supports 12V, 5V lasers with lifetime and no lifespan, the laser motherboard has an adjustable drive subdivision allowing three discs to be set simultaneously.
With end of stroke switch, tool adjustment interface, the laser also supports an external offline controller to realize offline control.In the meantime, the A4988 can be replaced by the 8825 driver.
3 axis control board is a 3 axis motion control system based on a processor, which can be used for laser engraving machine, plotter, typewriter, CNC engraving machine, etc.
