532nm 100MHz 1mm Free Space Acousto-optic Modulator

Category:

Description

532nm 100MHz 1mm Free Space Acousto-optic Modulator

Key performance

Low loss

Stable performance

Application

light switch

Laser wavelength shifting

parameter Unit Min Max conventional
material       TeO2
wavelength nm     532
Average optical power W   5
Peak (pulse) optical power kW   30
Ultrasonic sound velocity m/s     4200
Diffraction efficiency %   90 85
Center frequency MHz     100
Frequency shift MHz     +/-100
3dB bandwidth MHz     ±10
Passage aperture (length * width) mm     2*1
RF power W     0.7
Rising time ns   200
Voltage standing wave ratio       1.2:1
input resistance Ω     50
Deflection angle mrad     5
Device interface       SMA
Operating temperature     0~50
storage temperature     -30~70
