1550nm 40MHz Fiber Coupled Acousto-optic Modulator

SKU: aom-1550-40 Category:

Description

1550nm 40MHz Fiber Coupled Acousto-optic Modulator

Key performance

Low insertion loss

compact

Stable performance

parameter Unit Min Max conventional
material TeO2
wavelength nm 1520  1580 1550
Average optical power KW 0.5
Peak (pulse) optical power kW 1
Ultrasonic sound velocity m/s 4200
Insertion loss dB  2 3 2.5
Extinction Ratio dB 50 50
Return loss dB  40
Rising time ns 60  70 65
frequency MHz 40
Frequency shift MHz +/-40
RF power W 2.5
Voltage standing wave ratio 1.2:1
input resistance Ω  50
Device interface  SMA
Fiber type  SMF1550


Fiber length

m 1.2
Fiber optic interface



FC/APC
Operating temperature -20~+60
storage temperature -30~+70
